Skytech High, Medium, Low Remote Control, for AF-LMF-RVS Valve | RCAF-1035
Skytech High, Medium, Low Remote Control, for AF-LMF-RVS Valve | RCAF-1035
The Skytech RCAF-1035 is the ON/OFF and HIGH/MEDIUM/LOW remote control kit for the Skytech AF-LMF-RVS valve kit. A battery powered receiver drives a DC step motor on the valve, so you can switch the fire on and off and pick one of three flame settings from the transmitter. Skytech lists it as the remote that comes with the AF-LMF-RVS.
Details
| Model | RCAF-1035 |
|---|---|
| Type | Remote control kit, ON/OFF and HIGH/MEDIUM/LOW |
| Fits | Skytech AF-LMF-RVS valve kit |
| Flame control | HI/MED/LO DC step motor |
| Receiver | Battery powered RF, 4 x AA batteries; slide switch and LEARN button |
| System parts | Hand-held transmitter, receiver, DC step motor, 4-wire harness with 4-pin connectors, plastic receiver shield |
| Transmitters | Receiver stores up to 3 transmitter codes |
| Heat safety | Receiver shuts the system off at 130 degrees F |
| Brand | Skytech |
Questions people ask us
Will it work on other valves?
No. It is matched to the AF-LMF-RVS valve kit. For the AF-LMF-RV, the matching remote is the RCAF-1020-1.
How do I pair a new transmitter?
Set the receiver switch to REMOTE, press and release LEARN, and after the beep hold the transmitter's ON/OFF or H/M/L button for about 2 seconds. Rapid beeps confirm it. Holding LEARN for 10 seconds clears all codes.
What batteries does the receiver use?
Four AA batteries. Install them only after the step motor is plugged in, since the receiver calibrates the motor when the batteries go in.
Not sure it matches your valve?
Send us the valve kit model or a photo of the label and we will confirm it before you order. Ask us here.
