Skytech Variable Flame Remote Control, for AF-LMF-RV Valves | RCAF-1020-1
Skytech Variable Flame Remote Control, for AF-LMF-RV Valves | RCAF-1020-1
The Skytech RCAF-1020-1 is the variable flame remote system Skytech supplies with its AF-LMF-RV standing pilot valve kit. The transmitter has ON/HI, LO and OFF buttons, and the battery receiver sends up to 6 VDC to the DC motor on the valve to raise or lower the flame. It is a replacement or add-on remote for approved AF-LMF-RV valve systems only.
Details
| Model | RCAF-1020-1 |
|---|---|
| Type | Single function wireless remote control system |
| Works with | AF-LMF-RV valve kits |
| Buttons | ON/HI, LO and OFF |
| Output | Up to 6 VDC to the valve's DC servo motor |
| Transmitter | 12V A23 battery |
| Receiver | 4 x AA batteries |
| Range | About 20 feet |
| Security codes | 65,536 |
| Valve wiring | 18 gauge stranded black and red leads with 1/4" female terminals |
| Brand | Skytech |
Questions people ask us
Will it work with my valve?
It is made for the Skytech AF-LMF-RV valve kit, which uses a motor on the valve for flame adjustment. It is not a match for other valve systems, so send us your valve model if you are unsure.
How is the flame adjusted?
The receiver drives the motor on the valve when you press ON/HI or LO, raising or lowering the flame. OFF runs the motor for about 5 seconds to turn the flame down.
The buttons work backwards. What now?
Skytech's fix is to swap the two motor wires, either at the receiver or at the valve.
What batteries does it use?
The transmitter takes a 12V A23 battery and the receiver takes four AA batteries. Skytech notes that heavy ON, LO and OFF use shortens receiver battery life.
Not sure the RCAF-1020-1 is the right remote?
Send us the valve kit model or a photo of the valve label and we will confirm it before you order. Ask us here.
Goes with this
Manuals and warranty
Warranty terms come from Skytech and depend on the product. Read the manual and the warranty for your model before you order.
