Enervex SCA Steel Chimney Adapter for RS and RSHT Chimney Fans

Enervex SCA Steel Chimney Adapter for RS and RSHT Chimney Fans

$500.00
$500.00
Sale Sold out
Shipping calculated at checkout.
Enervex SCA Steel Chimney Adapter for RS and RSHT Chimney Fans
View full details

The Enervex SCA is a stainless steel adapter that mounts an Enervex chimney fan on top of a round steel chimney. A square plate carries the fan and a 5 inch deep round collar slides into the chimney for a snug fit. Choose the fan size and the chimney size: part numbers FR2008, FR2010, 221.0300.3006, 221.0300.3007, FR3010, FR3012, FR3014, FR3016, FR4012, FR4014 and FR4016.

5 in. deep collarSlides into the chimney
316L stainless16 gauge
6 to 16 in.Chimney sizes listed here
Single or double wallRound steel chimneys

Details

Part numbersRS 009 size: FR2008 (8 in.), FR2010 (10 in.). RS 012 or RS 014 size: 221.0300.3006 (6 in.), 221.0300.3007 (7 in.), FR3010 (10 in.), FR3012 (12 in.), FR3014 (14 in.), FR3016 (16 in.). RS 016 size: FR4012 (12 in.), FR4014 (14 in.), FR4016 (16 in.)
Enervex series221.0300 series in Enervex's SCA chart; FR2008 is 221.0300.2008, FR3010 is 221.0300.3010 and so on
UseMounting an Enervex RS, RSHT, RSV or GSV fan on a single or double wall round steel chimney
Flue sizeThe inside diameter of the steel chimney
Collar5 in. deep, outside diameter 1/8 in. smaller than the chimney inside diameter
Material16 gauge 316L stainless steel
InstallationSlides into the chimney; can be secured with long self-tapping stainless steel screws
BrandEnervex
Measure the inside diameter of the chimney.The collar is made 1/8 in. under the chimney inside diameter, so order by the actual inside size of the flue, not the outside of the pipe. An air cooled steel chimney needs the ASCA adapter instead.

Questions people ask us

How do I pick the right one?

Pick the fan size first, then the inside diameter of your steel chimney. For example, an RS014 on a 10 in. chimney takes FR3010. Send us your fan and chimney if you want us to check it.

Does it work with the RSHT fans?

Yes. Enervex makes the SCA for its RS and RSHT chimney fans. Its size chart is laid out by RS fan size, so send us your RSHT model and chimney size and we will confirm the part number with you.

My chimney is air cooled. Is this the right adapter?

No. For a double walled, air cooled chimney, Enervex uses the ASCA steel chimney adapter, which lets air move between the inner and outer walls.

Do I need it on a brick chimney?

Usually not. On a masonry chimney the RS and RSHT fans sit on the fiber mat supplied with the fan. The SCA is for round steel chimneys.

Goes with this

RS chimney fanFor gas fireplaces and stoves RSHT chimney fanFor wood and solid fuel ASCA adapterFor air cooled chimneys Chimney adapters and dampersParts that mount on the chimney

Manuals and warranty

Enervex manuals and warranty

Warranty terms come from Enervex and depend on the product. Read the manual and the warranty for your model before you order.

Our warranty library· SCA product information (PDF)
Not sure which adapter size you need? Send us the fan model and the inside diameter of your chimney and we will match the part number before you order. No obligation either way.
