SR Smith UF-24-102 U-Frame – 24 in Height, .065 Wall Thickness

What This Part Is Used For
This U-Frame provides the fixed-height structural base for SR Smith diving board installations requiring a 24 inch elevation. It supports the board mounting assembly and maintains proper board positioning.

Why This Part Matters
Board height and frame integrity directly affect diving board performance and safety. A weakened or incorrect frame can cause excessive flex or alignment issues. Replacing the U-Frame restores proper system geometry and load support.

Key Features and Specifications

• Manufacturer part number UF-24-102
• U-Frame support component
• 24 inch frame height
• .065 wall thickness
• Used in SR Smith diving board systems

Installation and Fitment Guidance
This frame must match the original diving board height and stand configuration. Installation is typically completed during board or structural replacement. Confirm by manufacturer part number before ordering.

About the SR Smith Brand
SR Smith designs pool equipment with consistent system compatibility across product lines. Their diving systems are engineered to meet industry standards while remaining service-friendly. Replacement components are built to integrate without modification.

Common Service Context
Technicians encounter this frame when correcting improper board height or replacing corroded supports. It is often identified during safety inspections or board retrofits.
