Waterway Plastics 519-3150 Vacuum Plate - 90 Degree

What This Part Is Used For
The Waterway Plastics 218-1890A Gunite Air Pipe Measuring Tool is used to measure and set correct air pipe depth in gunite spa and pool installations. It ensures that air lines are positioned accurately before gunite is applied. This tool helps maintain proper air injection performance once the system is operational. Builders use it during rough-in to avoid airflow restrictions. Accurate placement is critical for consistent jet aeration.

Why This Part Matters
Incorrect air pipe depth can reduce jet performance or introduce unwanted turbulence. Once gunite is applied, correcting pipe placement is extremely difficult. This measuring tool helps eliminate guesswork during installation. It ensures consistent results across multiple jets and air lines. Proper measurement prevents long-term performance complaints and rework.

Key Features and Specifications

• Manufacturer SKU 218-1890A
• Designed for gunite air pipe measurement
• Used during spa and pool rough-in
• Helps set proper air line depth
• Supports consistent jet aeration
• Reusable installation tool
• Intended for professional builders

Installation and Fitment Guidance
The tool is used during rough plumbing before gunite application. Technicians reference the tool to confirm correct pipe placement relative to the shell. It should be removed before final finishing. Compatibility depends on the air system design used. Confirm by manufacturer part number before ordering.

About the Waterway Plastics Brand
Waterway Plastics designs many of the air and jet systems used in modern spas. Their installation tools reflect years of builder feedback. Waterway focuses on reducing variability during construction. This leads to more consistent performance once systems are active. The brand is widely trusted by pool professionals.

Common Service Context
This tool is most often used during new gunite spa construction. Builders identify the need during air system layout. It is rarely used after finishing due to its rough-in purpose. Professionals recognize it as a setup gauge rather than a service tool.
