Hayward WG1049AVPAK2 Dual Suction Outlet Assembly - 2 inch

What This Part Is Used For
The Hayward WG1049AVPAK2 is a dual suction outlet assembly with 2 inch connections used in in ground pool circulation plumbing. It installs in the pool wall or floor and ties into the suction line feeding the pump. Dual suction bodies distribute intake across two openings for balanced draw.

Why This Part Matters
Correct suction configuration supports stable circulation and safer flow distribution at the pool. A cracked housing or mismatched connection size can lead to leaks behind the shell or restricted flow to the pump. Using the proper 2 inch assembly prevents replumbing and helps keep hydraulics consistent. This is a core component in the suction side layout.

Key Features and Specifications

• Manufacturer part number: WG1049AVPAK2
• Dual suction outlet assembly
• 2 inch connection size
• For pool wall or floor installation
• Compatible with Hayward dual suction covers and frames

Installation and Fitment Guidance
Install during construction or major renovation when plumbing access is available. Verify pipe sizing and layout before setting and bonding the body. Confirm by manufacturer part number before ordering.

About the Hayward Brand
Hayward supports complete residential pool systems with pumps, filters, heaters, automation, cleaners, chlorination equipment, and service parts. Their suction fittings and safety components integrate with Hayward hydraulic designs across common pool builds. This compatibility simplifies new installs and equipment upgrades. Hayward replacement parts are widely supported by builders and service pros.

Common Service Context
Technicians typically encounter this assembly during new builds, resurfacing, or drain body replacement. It is recognized by its dual layout and 2 inch plumbing connection during inspection.
