Hayward DCX105C Diaphragm

What This Part Is Used For
The Hayward DCX105C Diaphragm is a replacement internal diaphragm for compatible Hayward suction cleaners. It drives the pulsing action that moves the cleaner across the pool floor.

Why This Part Matters
A worn diaphragm causes weak movement or complete cleaner failure. Replacing it restores proper pulsing and suction efficiency. This helps maintain effective debris removal.

Key Features and Specifications

• Manufacturer part number DCX105C
• Cleaner diaphragm
• For compatible Hayward suction cleaners
• Drives pulsing propulsion system
• Service replacement internal component

Installation and Fitment Guidance
Disconnect the cleaner from the suction line before disassembly. Inspect internal housing for debris during replacement. Confirm by manufacturer part number before ordering.

About the Hayward Brand
Hayward suction cleaners are widely used in residential pool systems. Their internal wear parts are supported for routine service. Genuine Hayward diaphragms ensure proper fit and cleaner performance.

Common Service Context
Common during cleaner rebuilds. Often replaced when the cleaner stops moving but suction is present.
