Hayward AX6009S In-Line Filter Screen

The Hayward AX6009S was an in-line debris filter screen used within compatible hose filter sections on select Hayward pressure-side pool cleaners. Its purpose was to catch debris before that debris could travel farther into the cleaner's internal water path.

When the screen becomes clogged, torn, distorted, or missing, the cleaner may experience restricted water flow, reduced pressure performance, inconsistent movement, or increased exposure to debris-related damage.

Since AX6009S is discontinued, the best repair option depends on the surrounding assembly and the exact cleaner platform. The original part should not be replaced with an unverified universal screen.

For Hayward Phantom and Phantom Turbo Cleaners

The compatible assembly-level repair path is typically:

• Hayward AX6000HWA2 - Pressure Hose and Top of In-Line Filter Assembly

This assembly replaces the upper in-line filter section as a matched component when the original AX6009S screen is damaged or no longer available.

For Hayward Viper and Viio Turbo Cleaners

The compatible assembly-level repair path is typically:

• Hayward AX5600HWA2 - Pressure Hose and Top of In-Line Filter Cap Assembly

This assembly is specific to the Viper and Viio Turbo platform. Do not substitute it onto a Phantom-family cleaner without confirming fitment.

If the Screen Is Intact but the Filter Section Is Leaking

• Hayward AX5010G19 - In-Line Filter O-Ring

When the original screen remains intact and the issue is limited to a leaking in-line filter connection, the O-ring may be the appropriate repair instead of replacing the full upper filter assembly.

The AX6009S was used across more than one Hayward pressure-cleaner platform. Because the surrounding hose and filter-cap assemblies are not identical across all cleaner families, the correct alternative is not universal.

Confirm the following before ordering an alternative:

• Whether your cleaner is a Phantom, Phantom Turbo, Viper, or Viio Turbo model.
• Your original hose and in-line filter assembly configuration.
• The connector layout, hose connection, and cap style on the existing assembly.
• Whether the screen itself is damaged, or whether the problem is limited to an O-ring or leaking connection.

Shut off the pool pump and relieve pressure from the cleaner hose system before disconnecting the in-line filter section.

• Inspect the screen, cap, hose connection, and O-ring before ordering repair components.
• Clean debris from surrounding fittings before reassembly.
• Inspect the O-ring for flattening, cracking, tears, or loss of flexibility.
• Do not force incompatible hose or filter-cap components together.
• Confirm the cleaner model and replacement part number before installation.

Is Hayward AX6009S still available?
No. The Hayward AX6009S in-line filter screen has been discontinued and is no longer available as a standard standalone replacement part.

What replaces Hayward AX6009S?
There is no confirmed universal direct replacement screen. The appropriate repair path depends on the cleaner model: AX6000HWA2 for compatible Phantom and Phantom Turbo systems, or AX5600HWA2 for compatible Viper and Viio Turbo systems.

Do I need to replace my entire Hayward pressure cleaner?
Usually not. If the issue is limited to the in-line filter section, replacing the correct compatible assembly may restore the cleaner without replacing the full unit.

Can I use a generic aftermarket filter screen?
We do not recommend using a generic screen unless its dimensions, fitment, and sealing characteristics have been confirmed for your exact cleaner assembly.

What if the in-line filter section leaks but the screen looks fine?
Inspect the in-line filter O-ring. For compatible Hayward cleaner systems, AX5010G19 may be the appropriate repair when the issue is limited to the seal.

Please verify cleaner model and fitment before ordering any compatible replacement assembly. Keep all original packaging until fitment and operation are confirmed.

Review part numbers, hose connections, photos, and the existing cleaner configuration before installation. Electronic communication with a qualified pool professional may be helpful when the cleaner model or assembly layout is unclear.
